Victron Bluesolar Mppt 75/10 10a Solar Charge Controller For Solar Panels Up To 145w (12v) / 290w (24v) Up To 75v

Unlock the full potential of your solar panels with the Victron BlueSolar MPPT 75/10 Solar Charge Controller. This smart device is engineered to capture the maximum energy from your solar setup, giving you up to 30% more power than traditional systems. Plus, its unique BatteryLife feature actively protects your battery, significantly extending its lifespan. It's the ideal choice for anyone seeking reliable, efficient, and long-lasting solar power, whether for your RV, boat, or a remote off-grid system.

This advanced 10A MPPT solar charge controller comes from Victron's intelligent BlueSolar range. It uses ultrafast MPPT technology to constantly track the maximum power point of your solar panels. This ensures excellent performance even in challenging conditions like low light or cloudy weather, consistently pulling the most power from your solar array.

Key Features:

• Ultrafast MPPT Technology: Boosts energy yield by up to 30% compared to PWM controllers and 10% more than slower MPPT types.
• Intelligent 'BatteryLife' Function: Prevents battery over-discharge, automatically adjusting load disconnect levels to ensure a full weekly recharge and extending overall battery health.
• Built-in Safety Protection: Comprehensive safeguards against battery reverse polarity, load short circuits, and overheating, monitored via an internal temperature sensor. Features self-diagnostic capability with clear LED fault indicators.
• Automatic Voltage Selection: Smartly detects and adapts to either 12V or 24V battery systems.
• High Efficiency: Delivers over 95% efficiency for your entire solar system.
• Wide Battery Compatibility: Works seamlessly with AGM, Gel, Tubular plate, and Lithium batteries. (Note: Lithium battery settings may require a separate Bluetooth dongle or USB interface.)
• Robust & Durable Design: Built to withstand extreme temperatures (-30°C to +60°C), high altitudes, and marine environments. Features an IP43 water-resistant enclosure with resin-encapsulated internal electrical components.

Advanced Monitoring & Programming:

Take full control of your solar system with flexible monitoring and programming options:

• Optional MPPT Control Panel: Connects to the controller (sold separately) for direct access to key charging parameters (voltage, current, power) for your solar panel, battery, and load. It also provides useful 30-day performance data.
• VictronConnect App Access: Enhance your control by adding a VE.Direct Bluetooth Dongle or a VE.Direct USB cable (both sold separately). This unlocks the powerful VictronConnect App, compatible with Android and iOS smartphones, tablets, iPads, MacBooks, and Windows PCs/laptops.

With the VictronConnect App, you can access a wide range of advanced features, including:

• Live Data Transmission: View real-time information on solar panel output, battery voltage and current, battery state of charge, and load consumption.
• Detailed Data Logs: Review system activity for the past 30 days with in-depth daily logs or monthly summaries. Graphics display energy yield, peak power, charging stages, battery voltages, and error records.
• User-Defined Battery Charging Algorithm: Customize charging parameters such as absorption voltage, float voltage, and equalization settings to perfectly suit your battery type.
• Load Configuration: Choose from pre-set load management programs or create your own, including a handy streetlight function for automated nighttime lighting.

Specifications at a Glance:

• Max Solar Panel Voltage: 75V
• Max Solar Panel Power: 145W (12V) / 290W (24V)
• Terminals: 3 pairs (solar panel, battery, load) for wires up to 6mm²
• Automatic Temperature Compensation: -16mV / °C (12V) / -32mV / °C (24V)
• Communication Port: RS232 / TTL for VE.Direct accessories
• Self-consumption: 20mA (12V) / 10mA (24V)
• Working Temperature: -30°C to +60°C
• Safety Standard: IEC/EN certified
• Enclosure Protection: IP43 (electronic components) / IP22 (connection area)
• Dimensions: 100 x 113 x 40 mm
• Weight: 500g
• Mounting: 4 x 4mm diameter holes for easy installation

Invest in the Victron BlueSolar MPPT 75/10 Solar Charge Controller and gain complete control over your off-grid power. Experience significantly stronger performance, extended battery life, and complete peace of mind. This controller is more than just a component; it's the intelligent core of your solar system, ensuring you get the most out of every ray of sunshine, every single day.
